Anchorage is an integral part of earth retention and support of excavation design. When a sheet pile, soldier beam wall, or combi-wall application exceeds cantilevered parameters, the primary wall design is only as good as the anchorage designed to help maintain structural stability. Whether soil nails or tieback anchors to a deadman wall, Sixgen has a complete line of threaded bar and accessories available in all grades with standard corrosion protection systems. This turnkey material package allows Sixgen to offer our design and contractor partners a one-stop geostructural system.

‍

Micropiles are one of the fastest-growing deep foundation applications in the industry. Supplying all components for a successful installation can be tricky. We have in-house geostructural product specialists who understand the drilling contractors field challenges. From surplus and used threaded casing, to starter teeth and internal thread bar, Alameda has the staff and material to deliver your complete micropile system.

‍

H-Piles are used in pile foundations, marine structures, and bending/earth retention applications such as Soldier Beam and Secant Pile Walls, just to name a few. The recent development of heavier 16” & 18” sections has opened H-Piles up to a multitude of structural applications. Coupled with the availability of higher grades, H-Piles demonstrate material and installation savings compared to alternate foundation systems.

‍

Lorem ipsum dolor sit amet, consectetuer adipiscing elit, sed diam nonummy nibh euismod tincidunt ut laoreet dolore magna aliquam erat volutpat. Ut wisi enim ad minim veniam, quis nostrud exerci tation ullamcorper suscipit lobortis.

‍

Sheet piles walls are a cost-effective installation method for shoring and retention applications, often requiring an anchorage package to resist deflection. These packages include channel, waler, capping, threaded bar, bearing plates and hardware. Alameda has the steel material, fabrication capabilities and in-house drafting to deliver the entire assembly with shop drawings to complete your sheet pile application.

‍

​​Domestic and Import
OD: 2” through 36”
Wall Thickness: STD through 2.344” Specification/Grades:
API5L GRB, X42, X46, X52,X56, X60, X65
ASTM A106 GRB, GRC, A333 GR 6
PSL1 & PSL2 Lengths:
Single Random Lengths (20’s)
Double Random Lengths (40’s)

‍

Domestic and Import
OD: 2” through 26”
Wall Thickness: 0.154” through 1.00” Specification/Grades:
API5L GRB, X42, X46, X52, X56, X60, X65, X70, X80
ASTM A53B /ASME SA53B
PSL1 & PSL2 Lengths:
Double Random Lengths (40’s)
Triple Random Lengths (60’s)
Quads (80’s)

‍

Domestic and Import
Longitudinal (LSAW) and Helical Seam (HSAW)
OD: 20” through 72”
Wall Thickness: 0.375” through 2.00” Specification/Grades:
API5L GRB, X42, X46, X52, X56, X60, X65, X70, X80
ASTM A572 GR50
PSL1 & PSL2 Lengths:
Double Random Lengths (40’s)
Triple Random Lengths (60’s)
Quads (80’s)

‍
